Matrix COSEC
COSEC ARC DC200P
Two-Door Controller for Enterprise Security
The COSEC ARC DC200P is a compact, IP65-rated two-door access controller supporting multiple credentials including RFID and PIN. It features Power over Ethernet (PoE) support and is designed for offices, banks, data centers, and industrial facilities.
Key features
- Control two doors from one door controller; reduces hardware costs
- Mobile-based door access control via user's mobile device
- Multiple connectivity: Bluetooth, Wi-Fi, PoE+, Ethernet
- Secured communication with SSL encryption
- IP to Door technology eliminates long cables
- Power to locks and readers via PoE+
- Auxiliary device interface for fire alarms, motion sensors, relay devices
- Third-party reader support via Wiegand/OSDP V2.2 interface
Specifications
| Maximum Doors | 2 |
|---|---|
| User Profiles | 50,000 |
| Event Logs | 5,00,000 |
| Reader Interface | RS-485, Wiegand, OSDP (over RS-485) |
| Inbuilt Wi-Fi | YES (IEEE 802.11 b/g/n) |
| Inbuilt BLE | YES (1m–8m configurable range) |
| PoE/PoE+ Support | YES (IEEE 802.3 af/at) |
| CPU | Cortex A8 800 MHz |
| Flash Memory | 256 MB |
| RAM | 256 MB (DDR3 SDRAM @800MHz) |
| Operating Temperature | -10°C to +50°C |
| Dimensions | 140mm × 24mm × 80mm |
| Enclosure | Metal Aluminium Casing (Black) |
| Certifications | CE, RoHS, FCC, UL |
Specifications sourced from Matrix Comsec and may change without notice. Contact us to confirm the exact model configuration.
